2-Piece Cable Tie with Fir Tree Mount, 8.0"L, 0.30 - 0.31" Mounting Hole, 50lb, PA66HIRHS/PA66HS, OG/BK, 500/pkg
Art.-No. 156-04030
|
|
Copied
- Friction tab inside of fir tree allows tie to sit in mount without falling out prior to installation.
- Initial fir tree serves as a locating feature for assistance in blind assembly applications.
- Disc feature provides anti-rattle protection in high vibration applications.
| Application | Primarily designed for fixing cable harnesses in the automotive industry their simplicity, and ease of use, has seen these parts used in everything from aircraft, to switch-gear, to washing machines. |
| Color | Orange (OG), High Voltage (HV), Black (BK) |
| Description | Fir tree mounts with ties cables provide a secure grip in mounting holes and protect against dirt and other impurities. The mount provides low insertion and high extraction force, and slides along the cable tie for the proper orientation. This is sold as an assembly with the cable tie. |
| PART DESCRIPTION | T50RFT8-PA66HIRHS/PA66HS-OG/BK |
| Packaging Type | pack |
| Part No. | 156-04030 |
| Product Subfamily | Fir Tree Mount Cable Ties |
| Product family | Self-Affixing Cable Ties |
| Short Description | 2-Piece Cable Tie with Fir Tree Mount, 8.0"L, 0.30 - 0.31" Mounting Hole, 50lb, PA66HIRHS/PA66HS, OG/BK, 500/pkg |
| Type | T50RFT8 |
| UV Resistant | No |
|
|
|
| Bundle Diameter Max. (imperial) | 1.97" |
| Bundle Diameter Max. (metric) | 50.0mm |
| Bundle Diameter Min. (imperial) | 0.2" |
| Bundle Diameter Min. (metric) | 5.0mm |
| Cable Tie Closure | plastic pawl |
| Disc Diameter (imperial) | 0.63" |
| Disc Diameter (metric) | 16.0mm |
| Fixation Method | Fir tree for round holes |
| Height (imperial) | 0.05" |
| Height (metric) | 1.2mm |
| Height 2 (imperial) | 0.45" |
| Height 2 (metric) | 11.5mm |
| Identification Plate Position | none |
| Length (imperial) | 8.0" |
| Length (metric) | 202mm |
| Length 2 (metric) | 12.0mm |
| Min. Tensile Strength (imperial) | 50lbs |
| Min. Tensile Strength (metric) | 225N |
| Mounting Hole Diameter (imperial) | 0.30 - 0.31 " |
| Mounting Hole Diameter (metric) | 7.7 - 8.0 mm |
| Mounting Hole Diameter Max. (imperial) | 0.31" |
| Mounting Hole Diameter Min. (imperial) | 0.3" |
| Mounting Hole Shape | Round |
| Panel Thickness (imperial) | 0.02 - 0.26" |
| Panel Thickness (metric) | 0.8 - 6.0mm |
| Panel Thickness Max. (Imperial) | 0.26" |
| Panel Thickness Max. (Metric) | 6.0mm |
| Panel Thickness Min. (Imperial) | 0.02" |
| Panel Thickness Min. (Metric) | 0.8mm |
| Releasable Closure | No |
| Thickness (imperial) | 0.05" |
| Thickness (metric) | 1.2mm |
| Width (imperial) | 0.18" |
| Width (metric) | 4.6mm |
| Width 2 (imperial) | 0.35" |
| Width 2 (metric) | 9.0mm |
| Affixing Part Material | PA66HS |
| CE Certification | No |
| CSA Certified | No |
| Cable Tie Material | Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS) |
| Flammability | UL 94 HB |
| Halogen Free | Yes |
| Material | PA66HIRHS, PA66HS |
| Material | Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS), Polyamide 6.6 heat stabilized (PA66HS) |
| Operating Temperature | -40°F to +221°F (-40°C to +105°C) |
| Prop65 Warning | No |
| ROHS compliant | Yes |
| UL Recognized (US) | No |
