Solar Label, Reflective, SOLAR PV SYSTEM…SHUTDOWN, 6.0 x 4.0", VL, Red, 50/roll
Art.-No. 596-00886
|
|
Copied
- Made with UV-stable inks and materials for durability and weather resistance.
- Reflective properties to meet applicable NEC code requirements for reflective identification.
- Supplied with an aggressive adhesive to ensure long life.
- Meets NEC & IFC standards for printed text, character height, color and outdoor UV stability to pass inspections.
| Color | Red (RD) |
| Description |
HellermannTyton Pre-Printed Solar Installation Labels are designed to meet the requirements of the National Electrical Code® (NEC®) and the International Fire Code (IFC) as well as being acceptable to the Authority Having Jurisdiction (AHJ). Labels are made with durable UV-stable materials and adhesives that are designed to stick to both baked enamel and powder-coated surfaces. Where applicable, labels are made using reflective materials for first responder safety. Some pre-printed labels are printable using a thermal transfer printer when variable voltage or series data must be printed and displayed. |
| Key product features | pre-printed, chemical resistance, outdoor use, UV resistant |
| PART DESCRIPTION | RSDRD17-505/281-RD |
| Packaging Type | pack |
| Part No. | 596-00886 |
| Print Color | White (WH) |
| Product Subfamily | Solar Identification |
| Product family | Labels and Tags |
| Short Description | Solar Label, Reflective, SOLAR PV SYSTEM…SHUTDOWN, 6.0 x 4.0", VL, Red, 50/roll |
| Technical Description | Pre-Printed Solar Label, Reflective-2017 Code, Rapid Shutdown Label - Roof Hazard, 6.0" X 4.0", Vinyl, Yellow, 50/RL |
| Type | RSDRD17 |
| UV Resistant | Yes |
| Adhesive | Acrylic |
| Adhesive Operating Temperature | -40°F to +302°F (-40°C to +150°C) |
| BABA compliant | YES |
| CE Certification | No |
| CSA Certified | No |
| Halogen Free | No |
| Material | 505/281 |
| Material | Type 505/281, UV stabilized, reflective vinyl with clear polyester laminate (505/281) |
| Minimum Application Temp. | +50°F (+10 °C) |
| Operating Temperature | -40°F to +174°F (-40°C to +79°C) |
| Pre-Printed | Yes |
| Prop65 Warning | No |
| REACH Conformity | Yes |
| ROHS compliant | Yes |
| UL File Number [Logo] | MH16736 [RU], MH14382 [RU], MH11410 [RU] |
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | Yes |
| Warranty | Yes |
