1-Piece Cable Tie with Screw Mount, 8.5" Long, 0.2" Hole, 1.8" Max Bundle Dia, 50lb, PA66HS, Black, 100/pkg
Part No. 113-00060
|
Copied
- Reinforcement ribs between the screw mount and cable tie head provide additional strength for added bundle stabilty and security.
- Simple one piece design for quick and easy installation.
- Secures with a screw or bolt.
| Color | Black (BK) |
| Description | Screw Mount Cable Ties attach to existing holes using a screw or bolt to provide a fastening point to secure and route wire and cable bundles. Reinforced ribs between the screw mount and cable tie head provide additional strength for added bundle stability and security. |
| Global Part Number | T50MRX-PA66HS-BK |
| Mechanical Strength (imperial) | 40.0lbs |
| Mechanical Strength (metric) | 177.9N |
| Part Number | 113-00060 |
| Product Family | Self-Affixing Cable Ties |
| Product Subfamily | Screw Mount Cable Ties |
| Short Description | 1-Piece Cable Tie with Screw Mount, 8.5" Long, 0.2" Hole, 1.8" Max Bundle Dia, 50lb, PA66HS, Black, 100/pkg |
| Type | T50MRX |
|
|
|
| Bundle Diameter Max. (imperial) | 1.77" |
| Bundle Diameter Max. (metric) | 45.0mm |
| Bundle Diameter Min. (imperial) | 0.06" |
| Bundle Diameter Min. (metric) | 1.5mm |
| Cable Tie Closure | plastic pawl |
| Fixation Method | Screw Mount |
| Height (imperial) | .24" |
| Height (metric) | 6.0mm |
| Identification Plate Position | none |
| Length (imperial) | 8.0" |
| Length (metric) | 203.2mm |
| Min. Tensile Strength (imperial) | 50lbs |
| Min. Tensile Strength (metric) | 225N |
| Mounting Hole Diameter (imperial) | 0.2 " |
| Mounting Hole Diameter (metric) | 5.2 mm |
| Mounting Hole Shape | Round |
| Mounting Screw Type | 1/4" (M6) Screw |
| Releasable Closure (Y/N) | No |
| Width (imperial) | 0.2" |
| Width (metric) | 4.7mm |
| BABA compliant | YES |
| CE Certification | Yes |
| CSA Certified | No |
| Flammability | UL 94 V-2 |
| Material | PA66HS |
| Material | Polyamide 6.6 heat stabilized (PA66HS) |
| Operating Temperature | -40°F to +257°F (-40°C to +125°C) |
| Plenum Rating | AH-2 |
| Prop65 Warning | No |
| REACH Conformity | Yes |
| ROHS Compliant | Yes |
| UL File Number [Logo] | E64139 [C_RU_US_62275_Type11], E64139 [C_UL_US_63FN_Type21] |
| UL Listed (US and Canada) | Yes |
| UL Listed (US) | Yes |
| UL Recognized (US and Canada) | Yes |
| UL Recognized (US) | Yes |
| UV Resistant | Yes |
