2-Piece Cable Tie with Screw Mount, Unassembled Set, 15" L, M8 Hole, 120lb, PA66HIRHS, Black, 1000/ctn
Part No. 156-02482
|
Copied
- Anti-rotation pin eliminates movement of bundle when fastening bolt.
- Heavy duty mount with robust 120 lb tie delivers an ultra strong alternative to metal clamps.
- Assembly withstands vibrations and displacement forces.
- Metal bushing accommodates high tightening torque.
| Color | Black (BK) |
| Description | These heavy duty cable tie mounts, secured with mechanical fasteners, include an anti-rotation pin that keeps the mount and harness assembly in position during the torquing of the bolt or nut. They provide an attachment point for securing and routing a single bundle. The mounts provide the highest level of fastening for critical cable security. |
| Global Part Number | T120RCPCM8-TSSET-PA66HIRHSUV/PA66HIRHS-BK |
| Part Number | 156-02482 |
| Product Family | 2-Piece Tie Assemblies |
| Product Subfamily | Screw Mount Ties |
| Short Description | 2-Piece Cable Tie with Screw Mount, Unassembled Set, 15" L, M8 Hole, 120lb, PA66HIRHS, Black, 1000/ctn |
| Type | T120RCPCM8-TSSET |
| Bundle Diameter (imperial) | 0.20-4.13" |
| Bundle Diameter Max. (imperial) | 4.13" |
| Bundle Diameter Max. (metric) | 105.0mm |
| Bundle Diameter Min. (imperial) | 0.20" |
| Bundle Diameter Min. (metric) | 5.0mm |
| Cable Tie Closure | plastic pawl |
| Fixation Method | Screw Mount |
| Height (imperial) | 0.92" |
| Height (metric) | 23.5mm |
| Identification Plate Position | none |
| Length (imperial) | 15.0" |
| Length (metric) | 385.0mm |
| Min. Tensile Strength (imperial) | 120lbs |
| Min. Tensile Strength (metric) | 535N |
| Mounting Hole Diameter (imperial) | 0.33 " |
| Mounting Hole Diameter (metric) | 8.4 mm |
| Mounting Hole Shape | Round |
| Mounting Screw Type | M8 Screw |
| Releasable Closure (Y/N) | No |
| Stud Diameter (imperial) | 0.31" |
| Stud Diameter (metric) | 8.0 mm |
| Thickness (imperial) | 0.07" |
| Thickness (metric) | 1.8mm |
| Width (imperial) | 0.30" |
| Width (metric) | 7.6mm |
| Width 2 (imperial) | 0.87" |
| Width 2 (metric) | 20.0mm |
| Affixing Part Material | PA66HIRHSUV |
| CE Certification | No |
| CSA Certified | No |
| Cable Tie Material | Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS) |
| Flammability | UL 94 HB |
| Halogen Free | Yes |
| Material | PA66HIRHSUV, PA66HIRHS |
| Material | Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV), Polyamide 6.6, high impact modified, heat stabilized (PA66HIRHS) |
| Operating Temperature | -40°F to +230°F (-40°C to +110°C) |
| Prop65 Warning | No |
| ROHS Compliant | Yes |
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
| UV Resistant | Yes |
