2-Piece Soft-Grip Tie/Heavy Duty Mount, Unassembled Set, PA66HIRHSUV/TPE, Black/Blue, 500/ctn
Art.-No. 156-03169
|
|
Copied
- Cable tie and mount combination eliminates the need for multiple-sized fixed-diameter clamps.
- Soft TPE inner layer inhibits lateral movements on the bundle, especially on smooth tubing
- Pre-locking feature holds the cable tie in place before it is tensioned.
- Soft-grip cable ties can be removed with a screwdriver for maintenance.
| Application |
Soft Grip mounts are especially designed for use with Soft Grip ties. The versatile combinations provide a variety of flexible fastening options for fluid management / cooling systems in vehicles. The Soft Grip Series is a unique semi-customised part solution and designed to save time, money and development effort. The foot parts of the mounts can be adjusted to individual customer requirements. In the event of maintenance, the cable tie can be easily removed using a screwdriver. Only the cable tie then needs to be replaced, not the whole fixing element. |
| Color | Black (BK), Blue (BU) |
| Description | The Soft-Grip Cable Tie features a pliable TPE layer that protects sensitive wire bundles and tubes. The cable tie maintains a high tensile strength and low insertion force. Arrowhead and heavy duty mount options provide an all-in-one bundling and mounting solution. |
| PART DESCRIPTION | SGT100SHDM320SET-PA66HIRHSUV/TPE-BK/BU |
| Packaging Type | bag |
| Part No. | 156-03169 |
| Product Subfamily | Screw Mount Cable Ties with Soft-Grip |
| Product family | Self-Affixing Cable Ties |
| Short Description | 2-Piece Soft-Grip Tie/Heavy Duty Mount, Unassembled Set, PA66HIRHSUV/TPE, Black/Blue, 500/ctn |
| Type | SGT100SHDM320SET |
| UV Resistant | Yes |
| Bundle Diameter Max. (imperial) | 1" |
| Bundle Diameter Max. (metric) | 25.4mm |
| Bundle Diameter Min. (imperial) | 0.39" |
| Bundle Diameter Min. (metric) | 10.0mm |
| Cable Tie Closure | plastic pawl |
| Cable Tie Head Width (metric) | 16.0mm |
| Cable Tie Thickness Max. (metric) | 2.85mm |
| Fixation Method | Screw Mount |
| Height (imperial) | 0.81" |
| Height (metric) | 20.7mm |
| Identification Plate Position | none |
| Length (imperial) | 5.51" |
| Length (metric) | 140.0mm |
| Min. Tensile Strength (imperial) | 71lbs |
| Min. Tensile Strength (metric) | 315N |
| Mounting Hole Diameter (imperial) | 0.33 " |
| Mounting Hole Diameter (metric) | 8.31 mm |
| Mounting Hole Shape | Round |
| Releasable Closure | No |
| Width (imperial) | 0.5" |
| Width (metric) | 12.7mm |
| Affixing Part Material | PA66HIRHSUV |
| CE Certification | No |
| CSA Certified | No |
| Cable Tie Material | Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV) |
| Flammability | UL 94 HB |
| Halogen Free | No |
| Material | PA66HIRHSUV, TPE |
| Material | Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV), Thermoplastic Elastomer (TPE) |
| Operating Temperature | -40°F to +221°F (-40°C to +105°C) |
| Operating Temperature, 1000h | +320°F (+160°C) |
| Operating Temperature, 5000h | +257°F (+125°C) |
| Operating Temperature, 500h | +329°F (+165°C) |
| Prop65 Warning | No |
| REACH Conformity | No |
| ROHS compliant | Yes |
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
