Mini Ratchet P-Clamp, 0.15 - 0.31" Bundle Dia., FT6.5, PA66HIRHSUV, Black, 1000/carton
Art.-No. 151-03626
|
|
Copied
- One-piece ratchet closure design allows for easy installation during pre- or final assembly.
- Accommodates a range of diameters from 4-8 mm, reducing part inventory.
- Round fir tree mounting option means no additional fastener is needed and provides low push-in effort while maintaining high pull-out resistance.
- Clamp interior is designed to guide and center bundle to reduce pinching.
- Easy-release feature allows for quick adjustments and maintenance.
- Impact modified, heat and UV stabilized PA66 provides long-term durability, indoors and out.
Show more
Show less
| Application | The Ratchet P-Clamp family offers versatility when managing wires, cables and hoses. The robust design and durable materials make it ideal for heavy duty applications, both in- and outdoors. The one-piece adjustable clamp can be closed by hand to the desired diameter. The release feature provides easy and nondestructive removal of cables simply by using a flat-head screwdriver. This nondestructive release allows the clamp to be reused without removing or replacing any bolts or screws. The Ratchet P-Clamp is offered in four sizes and multiple mounting configurations. |
| Color | Black (BK) |
| Description | The Mini Ratchet P-Clamp family offers versatility when managing wires, cables and hoses. The clamp size and design make it an ideal P-clamp replacement for securing sensor wires, brake lines or other wires. The one-piece adjustable clamp can be closed by hand to the desired diameter. The release feature provides easy and nondestructive removal of cables simply by using a flat-head screwdriver. This release feature allows the clamp to be reused without removing or replacing any bolts or screws. |
| PART DESCRIPTION | 4-8RCFT6.5-PA66HIRHSUV-BK |
| Packaging Type | pack |
| Part No. | 151-03626 |
| Product Subfamily | Ratchet P-Clamps |
| Product family | Ratchet Clamps |
| Short Description | Mini Ratchet P-Clamp, 0.15 - 0.31" Bundle Dia., FT6.5, PA66HIRHSUV, Black, 1000/carton |
| Type | 4-8RCFT6.5 |
| UV Resistant | Yes |
| Bundle Diameter Max. (imperial) | 0.31" |
| Bundle Diameter Max. (metric) | 7.874mm |
| Bundle Diameter Min. (imperial) | 0.15" |
| Bundle Diameter Min. (metric) | 3.81mm |
| Fixation Method | Fir tree for round holes |
| Length (imperial) | 2.66" |
| Length (metric) | 67.7mm |
| Min. Tensile Strength (imperial) | 50lbs |
| Min. Tensile Strength (metric) | 223N |
| Mounting Hole Centers (imperial) | 0.98" |
| Mounting Hole Centers (metric) | 25.1mm |
| Mounting Hole Diameter (imperial) | 0.24 - 0.27 " |
| Mounting Hole Diameter (metric) | 6.1 - 6.9 mm |
| Panel Thickness (imperial) | 0.3" |
| Panel Thickness (metric) | 7.25mm |
| Width (imperial) | 0.69" |
| Width (metric) | 17.5mm |
| CE Certification | No |
| CSA Certified | No |
| Flammability | UL 94 HB |
| Halogen Free | Yes |
| Material | PA66HIRHSUV |
| Material | Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV) |
| Operating Temperature | -40°F to +221°F (-40°C to +105°C) |
| Prop65 Warning | No |
| REACH Conformity | Yes |
| ROHS compliant | Yes |
| Reusable (Yes/No) | Yes |
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
