Magnetic Bridle Ring, Small, ¾” Dia Ring, Neodymium Magnet/Steel 40lb Pull Force, 100/Box
Part No. 151-04034
|
Copied
- No drilling or extra hardware required – just secure to steel surface.
- Magnetic mounts are reliable even in debris, dirt, and oil.
- Use for permanent mounting or as a temporary installation tool.
- Reuse and reposition capabilities allow for a flexible mounting solution.
- Easily remove without residue.
Show more
Show less
| Color | Metal (ML) |
| Description | Magnetic bridle rings route cables by securing to steel surfaces without the need for a mounting hole. Simply attach cables within the bridle ring and position the magnet onto the beam, metal joist, ceiling channel, conveyor frame, or other steel surface. Magnetic bridle rings are ideal for supporting communication and data cables. The mounts are simple to secure and can attach to surfaces contaminated with oil or debris. Ultra-strong neodymium magnets are ideal as a permanent mount or for temporary applications. Reuse and reposition them for ultimate flexibility without needing to replace or repurchase parts. |
| Global Part Number | MAGBR40S-NDFEB45M/ST-ML |
| Magnetic pull strength (N) | 178N |
| Magnetic pull strength (kgf) | 18.15 |
| Magnetic pull strength (lb/ft) | 40lbf-ft |
| Part Number | 151-04034 |
| Product Family | Magnetic Mounts |
| Product Subfamily | Magnetic Bridle Rings |
| Rotation (°) | 0° |
| Short Description | Magnetic Bridle Ring, Small, ¾” Dia Ring, Neodymium Magnet/Steel 40lb Pull Force, 100/Box |
| Type | MAGBR40S |
| CE Certification | No |
| CSA Certified | Yes |
| Halogen Free | Yes |
| Material | NDFEB45M, ST |
| Material | Neodymium alloy 45M (NDFEB45M), Steel (ST) |
| Operating Temperature | -40°F to +176°F (-40°C to +80°C) |
| Plenum Rating | AH-2 |
| Prop65 Warning | No |
| REACH Conformity | Yes |
| ROHS Compliant | Yes |
| Reusable (Y/N) | Yes |
| UL File Number [Logo] | E64139 [cULus] |
| UL Listed (US and Canada) | Yes |
| UL Listed (US) | Yes |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
| UV Resistant | No |
