Convoluted Tubing, Slit, 1" Dia, PEUV, Black with Orange Stripe, 2250ft/carton
Art.-No. 904-00359
|
|
Copied
- Split side is ideal for applications where braided tubing or spiral wrap may be difficult to install.
- Tubing provides full coverage where spiral wrap or other coverings may not be suitable.
- In harsh applications the tubing provides resistance to crushing, impact, and abrasion.
- Tubing offers excellent protection against automotive fluids, vibration wear, water, snow, ice, and the effects of heat, cold, and sunlight on cables and wires.
| Color | Black with Orange Stripe (BKSTOG) |
| Description | HellermannTyton’s Convoluted Tubing, also known at Split Loom Tubing, provides an efficient method of routing and protecting wire harness assemblies, while reducing the chance of installation damage. With a split down the side where you can insert your wire harness, you can just easily install Convoluted Tubing without removal of the entire assembly. It can also serve to protect valuable hoses and cables. Convoluted tubing offer’s excellent protection against vibration wear, water, snow, ice and the effects of heat, cold and sunlight on cables and wires. |
| PART DESCRIPTION | CTPUV10-PEUV-BK |
| Packaging Type | pack |
| Part No. | 904-00359 |
| Product Subfamily | Flame Retardant Slit Convoluted Tubing |
| Product family | Convoluted Tubing |
| Short Description | Convoluted Tubing, Slit, 1" Dia, PEUV, Black with Orange Stripe, 2250ft/carton |
| Type | CTPUV10 |
| UV Resistant | Yes |
| Bundle Diameter Max. (imperial) | 1.06" |
| Bundle Diameter Max. (metric) | 27.2mm |
| Bundle Diameter Min. (imperial) | 0.1" |
| Bundle Diameter Min. (metric) | 1.0mm |
| Diameter (imperial) | 1.304" |
| Diameter (metric) | 33.13mm |
| Diameter 2 (imperial) | 1.069" |
| Diameter 2 (metric) | 27.16mm |
| Inner Diameter (imperial) | 1.069" |
| Inner Diameter (metric) | 27.16mm |
| Length (imperial) | 2250.0ft |
| Length (metric) | 685.8m |
| Nominal Diameter (imperial) | 1" |
| Nominal Diameter (metric) | 25.4mm |
| Outside Diameter (imperial) | 1.304" |
| Outside Diameter (metric) | 33.13mm |
| Outside Diameter 2 (imperial) | 1.304" |
| Outside Diameter 2 (metric) | 33.13mm |
| Trade Size | 1 " |
| Wall Thickness (imperial) | 0.006" |
| Wall Thickness (metric) | 0.152mm |
| CE Certification | No |
| CSA Certified | No |
| Flammability | not flame retardant |
| Halogen Free | Yes |
| Material | PEUV |
| Material | Polyethylene, UV-resistant (PEUV) |
| Operating Temperature | -40°F to +185°F (-40°C to +85°C) |
| Prop65 Warning | No |
| REACH Conformity | Yes |
| ROHS compliant | Yes |
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
