Double Connector Clip, 11mm, with 11mm Female Adapter, PA66HIRHSUV, Black, 2000/ctn
Art.-No. 151-03521
|
|
Copied
- 2 position - 11mm USCAR connector clip bank provides exceptional versatility for mounting of connectors.
- 11mm USCAR connector slot on opposite side provides options for incorporating many HellermannTyton connector clips with mounting features.
- Each connector clip and connector slot is designed to meet USCAR EWCAP-005-11 clip slot specifications.
- Meets installation and extraction requirements of SAE/USCAR-2.
| Application | The Connector Clips used here have been designed for electronic cables and cable sets used in the automotive industry. These parts are related to a connector and then secured to a surface depending on the requirement |
| Color | Black (BK) |
| Connection Type | USCAR11 |
| Description | Connector clips feature various attachment point configurations to accommodate the many connectors on the market. With so many configurations available, attachment surfaces can be a hole, edge, stud or even another harness assembly. |
| Global Part Number | DBLCC11BRKT-PA66HIRHSUV-BK |
| Packaging Type | bag |
| Part No. | 151-03521 |
| Product Subfamily | Connector Clips |
| Product family | Self-Affixing Clips |
| Short Description | Double Connector Clip, 11mm, with 11mm Female Adapter, PA66HIRHSUV, Black, 2000/ctn |
| Type | DBLCC11BRKT |
| UV Resistant | Yes |
| CE Certification | No |
| CSA Certified | No |
| Flammability | UL 94 HB |
| Halogen Free | No |
| Material | PA66HIRHSUV |
| Material | Polyamide 6.6 high impact modified, heat and UV stabilized (PA66HIRHSUV) |
| Operating Temperature | -40°F to +221°F (-40°C to +105°C) |
| Prop65 Warning | No |
| REACH Conformity | Yes |
| ROHS Compliant | Yes |
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
