High-Performance Extended-Length Tie Heads, POMUVCU, Black, 25/pkg
Art.-No. 904-02730
|
|
Copied
- Separate heads allow for any bundle diameter, eliminating waste.
- UV resistant materials contain an inhibitor which prolongs the life of the tie in outdoor environments.
| Color | Black (BK) |
| Description | Strong locking heads for extended length ties make them suitable for any bundle diameter, eliminating waste. The specially designed heads with copper alloy pawls provide a strong grip on cables and wires without damage during vibration or in extreme environments. Spacers are available for dual bundle applications. |
| PART DESCRIPTION | EL-H3-POMUVCU-BK |
| Packaging Type | pack |
| Part No. | 904-02730 |
| Product Subfamily | Aerial Support Cable Tie Heads |
| Product family | Cable Ties |
| Short Description | High-Performance Extended-Length Tie Heads, POMUVCU, Black, 25/pkg |
| Type | EL-H3 |
| UV Resistant | Yes |
|
|
|
| Cable Tie Closure | copper alloy pawl |
| Cable Tie Head Length (imperial) | 0.85" |
| Cable Tie Head Length (metric) | 21.5mm |
| Cable Tie Head Width (imperial) | 0.73" |
| Cable Tie Head Width (metric) | 18.7mm |
| Min. Tensile Strength (imperial) | 250lbs |
| Min. Tensile Strength (metric) | 1115N |
| Releasable Closure | No |
| Thickness (imperial) | 0.06" |
| Thickness (metric) | 1.50mm |
| Width (imperial) | 0.5" |
| Width (metric) | 12.8mm |
| CE Certification | No |
| CSA Certified | No |
| Flammability | UL 94 HB |
| Material | POMUVCU |
| Material | Polyacetal, UV-stabilized with copper pawl (POMUVCU) |
| Operating Temperature | -40°F to +185°F (-40°C to +85°C) |
| Prop65 Warning | No |
| REACH Conformity | Yes |
| ROHS compliant | Yes |
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
